MODEL |
HA-20W |
HA-40W |
|
Recommended Protection distance |
Outdoor |
20m |
40m |
|
Indoor |
50m |
100m |
|
Max. Arrival Distance |
200m |
400m |
|
Infrared Beam |
2 beams |
|
Detection System |
Simultaneous Cut-off of 2 Beams |
|
Light Source |
Pulsed Infrared |
|
Response Time |
50 - 700ms, Adjustable |
|
Alarm Output |
Relay On/Off output, Rating: AC / DC 30V 300mA max |
|
Power Supply |
10 - 26 DCV or 8 - 18 ACV non polarity |
|
Current Consumption |
TX |
7mA |
10mA |
|
RX |
27mA Max. |
|
Working Temperature |
-25 °C - 55 °C |
|
Tamper Output |
NC Contact, Rating: 24Vdc/500mA max. |
|
Optical Axis Adjustable Angle (Horizontal) |
180° (± 90°) |
|
Optical Axis Adjustable Angle (Vertical) |
20° (± 10°) |
|
Messure for Moisture/Frost/Dew |
Heating Cover (Optional) |
|
Material |
Polycarbonate (PC) |
|
Weight |
|
|
Remarks |
Black color |
